Offical Show Your Rig Off

procupine14 · Jun 15, 2009, 10:03 PM

Quote:

Originally Posted by Mousey

Looks like it could be worth taking a dremel to the case purely so you have more space to route cables through, at least it'll let airflow go through better that way

I've been there a lot. especially on the case before my Cosmos. I think I ended up taking half of the case apart by the time I ended up getting my computer a bigger home where everything actually fit properly.

madspec · Jun 21, 2009, 05:02 PM

Hey all , i have 2 rigs ... one for home and one for the road .

Home PC :

Intel Core 2 Duo E8400 @ 4.1 Ghz ( laped )
GIGABYTE GA-X48T-DQ6 DDR3
EVGA E-GeForce GTX295
4 X 1 Gig Kingston HyperX 1600MHz DDR3 Non-ECC CL7 7-7-7-20
Thermalright Ultra-120 eXtreme cpu cooler ( lapped )
1 X Western Digital Velociraptor 300 gb 10 000 rpm
2 X Seagate 1 TB SataII 32 MEG
3 X Seagate 500 gig SataII 32 MEG
AUZENTECH X-MERIDIAN 7.1 Sound Card
PS Xigmatek 850 watts
Zalman ZM-MFC2 Fan Controler
Cooler master Cosmos S RC1100 case
Dell WFP27 27" Flat Panl Display

Some Pics ....

And this is my " on the road " rig .

Asus W90VP A1

Intel® Core™ 2 Quad Processor Q9000 (2.0GHz Quad core)
18.4” Full HD (1920 x 1080) display
ATI Dual Radeon™ HD 4870 (512MB x 2) DDR3 DGE
640GB 7200RPM (320GB x 2) hard drive
6GB of RAM
Blu-ray disc combo drive
Built-in 2.0 megapixel camera with digital array microphone
Fingerprint reader
Bluetooth v2.0
Wireless 802.11 a/g/n
Genuine Windows Vista® Vista Ultimate 64 bit

Chaos · Jun 21, 2009, 05:41 PM

sweet

cbeasley0 · Jun 21, 2009, 06:52 PM

Had to scale these down, so they lost some detail:

Chaos · Jun 21, 2009, 08:15 PM

i like the DuOrb coolers

cbeasley0 · Jun 21, 2009, 09:36 PM

Quote:

Originally Posted by Chaos

i like the DuOrb coolers

Especially because the stock ati fans are terrible. It dropped the temperature on my card by almost 30 degs, even with my case as cramped as it is. Plus they're incredibly quiet and the LED's give it a sweet look.

Mac Daddy · Jun 22, 2009, 01:49 AM

Nice

Neshi · Jun 22, 2009, 02:16 PM

very nice.. I especially like the laptop. As I will need one for my studies I just checked what it would cost here. Didn't know how quickly I had to close the site

procupine14 · Jun 22, 2009, 03:24 PM

Looking good! I have to throw up some new pictures of the system after I get my new hosing and everything zip tied up.

cbeasley0 · Jun 23, 2009, 08:14 AM

Quote:

Originally Posted by procupine14

Looking good! I have to throw up some new pictures of the system after I get my new hosing and everything zip tied up.

I didn't know you were liquid cooling again. Didn't you sell your last pump and everything?

isaak · Jun 23, 2009, 11:38 AM

A quick photo of my system (specs in system specs tab)

Mac Daddy · Jun 23, 2009, 01:17 PM

Nice setup Isaak sure it works great

lepel · Jun 25, 2009, 03:13 PM

I got myself the Lian Li A05n and a brand new PSU (a Seasonic M12II 500W) the other day. Here's before and after pics of the interior. Note: the PC you see in the first pic was built by a shop, but I did the "transplant" into the new case myself. I'm pretty pleased with the wiring (and dusting

) tbh.

This is the case I had before: http://www.antec.com/Believe_it/product.php?id=NjY0.Now I have the Lian Li Industrial Co., Ltd.

~~RE III - Frankie~~ · Jun 25, 2009, 03:52 PM

Here's some new pics.
New case, motherboard, GPU, PSU, RAM, CPU Cooler Keyboard and Mouse since last photos.

The Zalman!

My new Microsoft Keyboard

I'll post an inside shot of the case soon. It should look good. The cooler I mean.

isaak · Jul 3, 2009, 12:43 PM

NEW CASE!!

IT's HUGE!!

Mac Daddy · Jul 3, 2009, 01:32 PM

Nice addition on the case Bro looking good

Bolletje · Jul 3, 2009, 03:22 PM

Quote:

Originally Posted by isaak

A quick photo of my system (specs in system specs tab)

Lol que? Is that your SATA-cable that is twisted? I shouldn't do that because you maybe get corrupt data? (physics).

Neshi · Jul 3, 2009, 05:11 PM

I've seen alot of builds where that has been done. If you don't twist it too tight, I doubt it can do harm

Bolletje · Jul 4, 2009, 01:44 AM

Quote:

Originally Posted by Neshi

I've seen alot of builds where that has been done. If you don't twist it too tight, I doubt it can do harm

But why should you take the risk when there is plenty of room available?

procupine14 · Jul 6, 2009, 10:19 PM

Quote:

Originally Posted by cbeasley0

I didn't know you were liquid cooling again. Didn't you sell your last pump and everything?

Yeah I wold off a lot of stuff but I bought all new stuff as of recently.

Lowfat · Jul 20, 2009, 06:06 AM

removed drive cage and swapped the GTX295 to the HD4890's.

lepel · Jul 20, 2009, 10:02 AM

Very neat as usual.

**kris23** · Jul 20, 2009, 10:08 AM

how good is that V10?

Lowfat · Jul 20, 2009, 10:16 AM

Quote:

Originally Posted by kris23

how good is that V10?

pretty decent IMO. Mine however is modded a bit. Instead of the 70W TEC/peltier, I am running a 125W one. I don't know how much of a difference in temps it gives though. But I found that it did to a bit better than the TRUE black that I had before it.

Mac Daddy · Jul 20, 2009, 01:33 PM

Very nice and clean man how are the 4890's working for you?

**kris23** · Jul 20, 2009, 05:04 PM

i lol at the SSDs that are just sitting tight at the bottom of the case......

so you dont burn out any control mechanism by upgrading the TEC?

Lowfat · Jul 20, 2009, 07:46 PM

Quote:

Originally Posted by Mac Daddy

Very nice and clean man how are the 4890's working for you?

The only game I've played with them is STALKER Clear Sky, and the microstuttering is rather annoying w/ high details. I never played the game with the GTX295 so I can't compare it to it though. Might have been the same. I'll try out Crysis in the next few days to see how she does.

Quote:

Originally Posted by kris23

i lol at the SSDs that are just sitting tight at the bottom of the case......

so you dont burn out any control mechanism by upgrading the TEC?

Actually the SSD's are raised off the floor by about a cm buy a bunch of pennies

And I don't use the stock V10 parts. The 120W TEC is powered by its own dedicated power supply. It is hooked up to a relay that shuts the TEC off when the PC turns off.

DJ BIG T · Jul 20, 2009, 09:00 PM

very nice lowfat..

Lowfat · Jul 20, 2009, 09:16 PM

Quote:

Originally Posted by Neshi

I've seen alot of builds where that has been done. If you don't twist it too tight, I doubt it can do harm

You can twist it as tight as you want and it won't cause data corruption. Its a digital signal, the signal is either going to arrive or its not. When I coil my cables like that, I wrap them around a 3-4mm thick screwdriver.

Quote:

Originally Posted by Bolletje

But why should you take the risk when there is plenty of room available?

There is almost no risk and it makes things look quite a bit neater.

Coresong · Jul 21, 2009, 05:45 PM

My goal was to make a low key, living room suitable semi-hidden and totally quiet computer. I went to somewhat extremes, hand building a wooden frame to act as a side table / radiator shroud / coolant overflow catcher and be somewhat acceptable to wife as "furniture". End result is not bad looking, completely silent (despite 14 fans . ..)

The tech details:

intel Core i7 extreme 965
Asus W6T6 WS Revolution
2x nvidia GTX295 water cooled in quad SLI
2x intel 160GB SSD as Raid 0
1x 300gb raptor
1x 1TB WD
Koolance 1200watt watercooled oil immersed PS
MIPS North /south bridge waterblock
Mosfet water blocks
2 x (4 x 120mm) radiators
1/2 ID 3/4 OD tubing throughout
3x2Gb Corsair dominator DDR3 2000
Lian Li A71A case

CPU & MOSFET water blocks

Northbridge & Southbridge MIPS waterblock (ordered from some obscure store in germany... not an easy find..)

The whole mother board partially plumbed..

Mostly plumbed . .. just one card outlet missing..

Filled and degassed .....

underside of the top 4 fan radiator

Internal hard drive cage . . .

back side showing the back radiator install , plus the the water cooled powersupply..

Side on , top off showing top radiator fans

Finished product, from rear ...

Finished rig with top on ...

It is totally silent, tops out at over 35,000 3dVantage benchmark .... have gotten it OC'd to 4.6GHZ for brief time (the MB temps get high, not enough air movement over non WC'd parts), I was running at 4.2 GHZ util weather got hot, it dumps a HUGE amount of heat into the room. Running at stock clocks till the weather cools off or I really want to max some 3D FPS....
